Ultra compact and thin. (1.6×1.0×0.5mm)
Excellent electric performance optimum for mobile communications, OA (office automation) and AV (audiovisual) applications are exhibited.
A surface-mount crystal oscillator. (Reflow soldering is possible.)
Lead-free. Meets the requirements for re-flow profiling using lead-free solder.
| Type | S1610 |
| Freq. | 32.768kHz |
| Frequency tolerance (at 25℃) | -/+20ppm , -/+50ppm |
| Operating temperature | -40 ~ +85℃ |
| Equivalent series resistance | 90K ohms Max. |
|
Temperature characteristics -Turnover temperature -Parabolic curvature constant |
25°C ± 5℃ -0.045x10 -6 /℃ 2 Max. |
| Drive level | 0.1uW |
| Shunt capacitance | 2.0pF Max. |
| Load capacitance | 12.5pF , 9.0pF |
| Insulation resistance | 500M ohms//DC 100V |
| Aging | -/+3ppm/year |
| Min. Packing | 5,000pcs/Reel |
